Marantz 150

Opublikowano: 09 luty 2011
5.00


Kategoria: Tunery Radiowe
Producent: Marantz
Dodany przez: xwojtek PL

OPIS:

Marantz 150 - taki piękny tuner :-)
Zapytaj o sprzęt
Ocena
5.00
Zaloguj się by oceniać

Recenzje użytkowników

Użytkownik: piootr
10-02-11
5.00

Marantz Model 150 Tuner

General
Rarity X-Rare
Retail Price 599.95, June 20th 1975 Marantz Dealer List
Resale Value $600+
Designed in USA
Manufactured In Japan
First Year 1975
Last Year 1980
Blue Face Yes
Channels Two, four for scope
Tube Design One (Scope)
AC Switch Yes
Fusing Rear deck
Switched AC Outlets One @ 100 watts
Unswitched AC Outlets One @ 200 watts
Power Source Details Standard 120 VAC
Power Consumption 40 watts

Physical
Panel Width 15 3/8
Panel Height 5 3/4
Height 5 3/8 (without feet)
Depth 11 7/8
Weight 26 lbs, 33.5 lbs packed

FM Tuner
Gyro Tuning Yes
RF Sensitivity 1.2 uV
300 Ohm Binding Posts Yes
75 Ohm Binding Posts Yes
50 dB quieting sensitivity, Stereo 40 uV
50 dB quieting sensitivity, Mono 2.2 uV
Ultimate Quieting 75 dB
THD, Mono 0.15%
THD, Stereo 0.30%
Frequency Response 30 Hz to 15 kHz, +/- 1 dB
IF Bandwidth(s) Phase Linear 200 kHz
Capture Ratio 1.0 dB
IF Image Rejection 105 dB
IF Rejection 105 dB
Alternate Channel Selectivity (wide or normal) 085 dB
Spurious Rejection 105 dB
AM Carrier Rejection 65 dB
Stereo Separation at 1 kHz 45 dB
Mono Switch Yes
Stereo Only Switch Yes
Multiplex Filter (Hi-Blend) Hi-Blend
Attenuator Yes, rear deck -20 dB
Stereo Lamp Yes
Dolby Lamp Yes
Hi-Blend Lamp Yes
FM Mode Lamp Yes
Muting Switch Yes
Muting Adjustment On rear deck
Output Level Adjustment L,R on rear deck
25 uS Deemphasis Switch (Dolby Associated) Yes
Quadradial Output (FM Discriminator output, unequalized) Yes, 300 mV, 15K +/- 75 kHz deviation
Oscilloscope Yes
Scope Horizontal Position Adjustment Yes
Scope Vertical Position Adjustment Yes
Scope Brightness Adjustment On rear deck
Scope Focus Adjustment On rear deck
Scope External Audio Display Capability Front and rear
Scope Internal Audfio Display Capability Yes
Scope External Audio Gain Control Front and Rear
Scope Tuning Indication Yes
Scope Multipath Indication Yes
Illuminated Dial Pointer Yes

AM Tuner
RF Sensitivity 20 uV
Alternate Channel Selectivity 48 dB (alt chan)
Image Rejection 70 dB
Signal Strength Metering via Scope
External Ferrite Antenna Yes
Antenna binding Posts Press-n-clamps
