Sony STR-313LX

Opublikowano: 06 sierpień 2010
0.00


Kategoria: Amplitunery
Producent: Sony
Dodany przez: audiofilek PL

OPIS:

Sony STR 313LX

Specifications:

General
System: Transistor Receiver
Colour: 1=Silver, 2=Black: 1
Power consumption: 180 W @ 120/240 V
Pre Amplifier
Inputs: 1 Phono; 1 Tape
Quadro: no
Inp. Sensitivity High Level: 150 mV
Inp. Impedance High Level: 100 k?
Signal/Noise High Level: 90 db
Inp. Sensitivity Phono MM: 2.5 mV
Inp. Impedance Phono MM: 50 k?
Signal/Noise Phono MM: 70 db
Outputs: 1 Rec out (RCA)
Harmonic Distortion: - 0.5 % at rated output
Output Voltage Rec Out: 150 mV
Impedance Rec Out: 10 k?
Equalizer
Tone Controls: Bass; Treble
Frequencies: Bass ± 8 dB/100 Hz; Treble ± 8 dB/10 kHz
Filters: no
Loudness: + 8 dB/100 Hz; + 3 dB/10 kHz

Power Amplifier
Speaker Outputs: 1 x 2 Speakers; Phones
Continuous power 8?: 27 + 27 Watts
Dynamic Power 8?: 45 + 45 Watts
Frequency Response: 10-40,000 HZ
Damping factor: 20 ?
Harmonic Distortion: - 0.5 % at rated output

Tuner
Display: analog
Frequency Range FM: 87.5-108 MHz
Frequency Range AM: 530-1,605 KHz
Frequency Range SW: 5.8-15.8 MHz
Frequency Range LW: 150-350 KHz
Signal Strength Meter: 1 : 0=NO, 1=YES
Center Tuning Meter: 1 : 0=NO, 1=YES
Inp. Sensitivity Mono: 1.7 µV
Frequency Response: 30-15,000 HZ
Harmonic Distortion: 0.2 (Mono); 0.3 (Stereo) % at rated output
Separation: > 40 db
Signal/Noise Mono: 75 db
Signal/Noise Stereo: 70 db
Pilottondämpfung: 35 db

Physical
Dimensions in Inches: 16 x 5.7 x 12 (w) x (h) x (d)
Dimensions in mm: 410 x 145 x 310 (w) x (h) x (d)
Weight in lbs: 16.75 lbs
Weight in Kg: 7.6 Kg

www.classic-audio.com/sony-str313-p-257.html
