SPECIFICATIONS:
- Damping Factor; @20Hz >60!!!
- 0.08% THD at full rated power
- Freq Response Bandwidth of power amp section; 20-20,000Hz
- Rated Power 250 wpc @ 8 and 330 wpc @ 4 ohms

PRE-AMP SECTION;
- S/N ratio of phono input; 98 dB
- Freq Response; 10 Hz to 60 kHZ
- Output Levels for Tape; .775 mV
- Pre-Output max level; 4.2 V
- Pre-Out Impedance; 450Ω
- Tape Output Impedance; 500Ω
- Bass Control; centered @ 100Hz
- Treble Control; +- 11dB centered @ 10KHz
- Low Filter; Centered @ 15 cycles
- Hi-Filter; Centered @ 9 kHz

TUNER SPECS FOR FM;
- Sensitivity; IHF Usable - 8.75 dBf (1.5 μV)
- IHF 50 dB Quieting in Stereo Mode - 33.2 dBf (25 μV)
- 80 db S/N
- 85 dB Selectivity
- 1.0dB Capture Ratio @65 dBf (1000 μV)
- IF rejection; 120 dB
- FM separation @ 1kHz 50 dB

PHONO INPUT SECTION;
- Input overload at 200 mV
- Dynamic Range; 106 dB
- Input Sensitivity; 1.8 mV
- Input Impedance; 47 kΩ
- Input Capacitance; 100 pF
- S/N ratio of phono input; 80 dB
- Freq Response; 10 Hz to 60 kHZ
