Retail Price 449.95
First Year 1971
Last Year 1976
Wood Case WC-22
Blue Face Yes
Channels Two
Speaker Connections Two sets
AC Switch Yes
Switched AC Outlets One
Unswitched AC Outlets One
Power Consumption 310 watts
Physical
Panel Width 17 5/16
Panel Height 5 3/4
Width 16 7/8
Height 5
Depth 14
Weight 32 lbs, 45 shipped
Amplifier
RMS Power Per Channel 45
Total Harmonic Distortion (THD) 0.3%
Power Bandwidth 20 Hz to 20 kHz
Intermodulation Distortion (IM) 0.3%
FM Tuner
Gyro Tuning Yes
RF Sensitivity 2.5 uV
50 dB quieting sensitivity, Stereo 50 uV
50 dB quieting sensitivity, Mono 5.0 uV
THD, Stereo 0.40%
Capture Ratio 1.8 dB
Stereo Separation at 1 kHz 40 dB
Signal Strength Meter Yes
Center Tuning Meter Yes
Attenuator Switch on rear deck
Stereo Lamp Yes
FM Mode Lamp Yes
Muting Switch Yes
Quadradial Output (FM Discriminator output, unequalized) Yes
Illuminated Dial Pointer Yes
