Sansui QD 5500
4-channel stereo tapedeck

1973-1975



4-track, 2-channel stereo tape recording deck with auto-reverse playback & 4-track 4-channel tape recorder & 4-channel playback deck

Operation system

Solenoid drive, direct switch able function buttons.

Heads

3 Total:
1 4-channel Erase

1 4-channel Record

1 4-channel Playback

Motors

3 Total:
1 Capstan drive motor (duel speed hysteresis synchronous)
2 Reel base drive motors (eddy current induction)

Maximum Reel Size

7-inch

Tape Speed

2 Speeds
7-1/2ips
3-3/4ips +/-0.5%

Fast Forward/Rewind Times

90 seconds for 1,200 feet

Wow and Flutter

less than 0.07% WRMS 7-1/2ips
Less than 0.12% WRMS 3-3/4ips

Signal-to-Noise Ratio

Better Than 60dB

Total Harmonic Distortion

Better than 0.15% @ 1K

Frequency Response

7-1/2ips 15Hz to 25,000Hz (20Hz to 20,000Hz +/-3dB)
3-3/4ips 15Hz to 15,000Hz (30Hz to 12,000Hz +/-3dB)

Channel Separation

Better than 60dB at 1,000 Hz

Inputs
(Sensitivity/Maximum allowable level/input impedance)

MIC x 2: 0.5/(50Kohms), 6mm diam. jacks
LINE x 2: 70mV/100k Ohm or more

Outputs
(Reference level/Maximum level/Load impedance)

LINE x 2: .47V/10k Ohm or more
HEADPHONES 50mV/8Ohm,6mm diam. jack



Power Requirements

AC 100/117/220/240V 50/60Hz

Power Consumption

110 watts, Max. (UL)

Dimensions

16-5/8\" (W) x 21-7/8\" (H) x 10-5/8\"(D)

Weight

53.4 lbs. unpacked
